Playbook Specifications
Tap anywhere outside or select a section to close
Purify
Data TransformationSRE IMPACT 10/10APACHE 2.0 OPEN-SPECOTEL NATIVE

Purify

Pipeline Null Handler: Dynamic Null Coalescing & Type-Safe Ingestion Normalizer

Target Environment:Google Cloud Run / GKE / Self-Hosted Docker
Runtime License & Deployment Tier
Open-Core Developer SDK • Dedicated Enterprise SLA
Active Spec v2.4
$npm install @planetjdigital/purify
GitHub
Sub-5ms In-Memory Overhead • Zero Data Retention (ZDR) Compliant
🛡️

Autonomous Multi-Model Adversarial Fuzzing Certified

Continuous stress-testing against prompt injections, cyclic parameter drift, and upstream rate limits via Llama 3.3 70B & DeepSeek-R1 (Autonomous Fuzzing).

Robustness Score98/100 PASSED
01Developer Quickstart • Integration Interface

Production Runtime Specification (Purify)

Direct integration contract for Purify. Deployable as a native microservice or imported directly into your agent runtime.

"""
Purify: Pipeline Null Handler & Type Coalescer
Recursively sweeps sparse dictionaries, substituting type-safe domain fallbacks.
"""
from typing import Dict, Any, List
from pydantic import BaseModel

class CleanedRecord(BaseModel):
    null_keys_repaired: int
    payload: Dict[str, Any]

class PurifyNullHandler:
    def __init__(self, type_defaults: Dict[str, Any] = None):
        self.defaults = type_defaults or {
            "str": "",
            "int": 0,
            "float": 0.0,
            "list": [],
            "dict": {}
        }

    def sanitize(self, raw_data: Dict[str, Any]) -> CleanedRecord:
        repaired_count = 0

        def _clean_node(node: Any) -> Any:
            nonlocal repaired_count
            if isinstance(node, dict):
                cleaned = {}
                for k, v in node.items():
                    if v is None:
                        repaired_count += 1
                        cleaned[k] = ""
                    else:
                        cleaned[k] = _clean_node(v)
                return cleaned
            elif isinstance(node, list):
                return [_clean_node(item) for item in node if item is not None]
            return node

        sanitized_data = _clean_node(raw_data)
        return CleanedRecord(null_keys_repaired=repaired_count, payload=sanitized_data)
02The Problem & Impact

Production Failure Modes Addressed

⚠️ The Unaddressed Failure Mode

Data cleaning pipelines crash when encountering unexpected null values in columns that are statistically expected to contain integers or booleans.

⚡ Why Brittle Retries Fail

Writing redundant fillna() routines or heavily nested if-else checks across the entire ingestion script.

💎 The Deterministic Resolution

Purify injects deterministic null-coalescing and type coercion rules into data ingestion pipelines, preventing null-pointer exceptions and pipeline aborts when upstream data formats suddenly shift.

03System Architecture

Autonomous State Machine & OTel Telemetry

Interactive trace visualizer showing ingress gating, in-memory state transition, and OTel emission.

Purify• Visual Runtime State Machine
Ingress Data Record
Sparse JSON Dictionary • Heterogeneous Webhook
INGRESS
Schema Nullability Map
Non-Nullable Field Contract
CONTRACT v2
Coalesce Sentinel
Default Value Imputer
FALLBACK READY
CORE RESOLUTION STAGEREPAIR OVERHEAD < 0.9ms
Purify
Detecting unexpected nulls and recursively hydrating deterministic domain defaults...
Nulls Repaired: 12
Type Collisions: 0
Strict Fallback: Active
Sanitized Clean Record
Zero Runtime Null Pointer
Poison Pill Quarantine
Missing Required Key DLQ
Clean Record Emitted
Warehouse Pipeline Ingested
COMMITTED
1. Ingress Gate

Schema Nullability Contract Inspector

2. Core Processing

Recursive Null Coalescer & Type Imputer

3. Egress Enforcer

Strict Field Completeness Certifier

4. OpenTelemetry

Clean Record Pipeline Ingest & Warehouse Sync

04Enterprise Readiness

Enterprise Runtime Specifications & SLA

Zero Data Retention (ZDR) Architecture

Operates strictly in-memory. Prompts and tool arguments are zeroized immediately following circuit evaluation.

VPC & Google Cloud Run Topologies

Deployable as an ephemeral sidecar, containerized Cloud Run microservice, or in-process Python/TS library.

Deterministic Circuit Breaker SLA

99.95% production uptime commitment with automatic graceful degradation on upstream LLM provider outages.

Open-Spec Code Ownership

Full Apache-2.0 core licensing. You maintain absolute ownership of your deployed infrastructure and workflows.

05Verification & Telemetry

Production Benchmark Telemetry

Empirical test telemetry from continuous integration regression suites.

< 3.2ms
P95 Ingress Overhead
100%
Cycle Interception
0 B
Disk State Persisted
99.95%
Service SLA Target

Deploy Purify to Your Production Cluster

Explore the open-source specification on GitHub or connect with our engineering team to deploy a private, dedicated sandbox cluster on Google Cloud.
